Vega ALT-5 - MGL Avionics
Click to enlarge
HomeVega Singles ALT-5
Previous product
SP-7 - MGL Avionics
SP-7 $760.00
Back to products
Next product
Vega ASI-4 - MGL Avionics
ASI-4 $370.00 – $395.00

ALT-5

$405.00

2 1/4″ Digital Altimeter and Vertical Speed Indicator

In stock (can be backordered)

Complete Your System!
Vega ALT-5 - MGL Avionics
This item: ALT-5

In stock (can be backordered)

$405.00
$405.00
Gray Code Converter - MGL Avionics
1 × Serial to Gray Code Converter

In stock (can be backordered)

$159.00
Add Gray code converter to convert from serial data to parallel gray code.
Compare
Add to wishlist
SKU: ALT-5 Category: Vega Singles
Share
Facebook Twitter Pinterest linkedin Telegram
  • Description
  • Additional information
  • Reviews (0)
  • Vega Drawing
  • ALT-5 Manuals
Description

ALT-5 Precision encoding altimeter and VSI indicator

The ALT-5 is a 2 1/4” sunlight readable encoding altimeter and a wide range vertical speed indicator. The altimeter contains an internal high accuracy 24 bit digital altitude sensor which calculates altitude from -1000 ft up to a maximum of 35000 ft. The ALT-5 outputs various formatted RS232 serial data protocols compatible with serial input transponders such as that from Garmin, Magellan, Northstar, Trimble, Microair etc. The altimeter can display altitude in feet or meters and local pressure can be set in millibars or inches of mercury.

The VSI indicator can be displayed in either feet/minute (ft/min) or meters/second (m/s). The VSI can be calibrated by the user once the instrument has been installed in the aircraft.

The ALT-5 also features a user settable altitude bug and an encoder test function. The ALT-5 provides a parallel Gillham code interface when used in conjunction with the MGL Avionics CNV-ALT.

  • An internal high accuracy 24 bit digital altitude sensor calculates altitude from –1000 ft up to a maximum of 35000 ft (-304m to 10668m)
  • The ALT-5 outputs various formatted RS232 serial data protocols compatible with serial input transponders such as that from Garmin, Magellan, Northstar, Trimble, Microair etc.
  • Provides a parallel Gillham code interface for transponders when used in combination with the MGL Avionics CNV-ALT
  • Built in encoder test function
  • The altimeter can display altitude in feet or meters
  • Local pressure can be set in millibars or inches of mercury
  • Contains a wide range VSI indicator from +/-20 ft/min to as high as +/-10000 ft/min
  • VSI units can be in feet/minute (ft/min) or in meters/second (m/s)
  • User-set altitude preselect bug
Additional information
Power Specs

Voltage Input: 8-30 Volts DC with Over Voltage and Reverse Polarity Protection
Current Draw (13.8V): 73mA Backlight High, 33mA Backlight Low

Screen

Size: 1.8"
Resolution: 160×128
Backlight: 1000 cd/m2 brightness, sunlight readable LED backlight

Physical Specs

Unit Size: 60mm x 60mm x 68mm
Fits in: 2 1/4" Instrument Cutout
Weight: 120 grams (excluding wiring)

Brand

MGL Avionics
